DDL-8700L

1-needle, Lockstitch Machine for Leather and Heavy Materials

Features

  • With its reduced vibration and noise and easy operation of the feed lever at the time of reverse stitching, the machine promises to make sewing work more comfortable
  • Larger needle bar stroke (35 mm), and higher lift of the presser foot (13 mm) enable easy handling of heavy material
  • The machine is equipped with a handwheel that is larger than normal for easy turning.
  • The machine has an attachment mounting seat.Makes it easier to replace attachments and increases the durability of the machine bed.
  • Machine is equipped with a feed eccentric pin. This enables easy adjustment of the feed dog inclination and feed timing(phase), thereby offering improved maintainability
  • The stitch length can be adjusted to a maximum of 7mm
  • The machine runs at higher sewing speeds than any other lockstitch machine intended for heavy materials anywhere in the world, reaching, up to 4,000sti/min for stitch length of less than 5mm and 3,500sti/min for stitch length of up to 7mm. The result is dramatically increased productivity
  • The hook, gauge, and thread take-up lever are all exclusively designed for the DDL-8700L to enhance its ability to produce beautiful well-tensed seams.
  • By adopting the locus best suited to the sewing of leather and heavy materials, the machine smoothly feeds heavy materials without stitch gathering even on multi layered portions. The machine also uses a fluorocarbon resin presser foot that offers sharp-curve sewing capability to prevent from scratch on the material

Technical Specifications

Model Name DDL-8700L
Max. sewing speed

4,000sti/minˎ(for stitch length less than 5mm)

3,500sti/minˎ(for stitch length up to 7mm)

Max. stitch length 7mm(normal/reverse feed)
Needle bar stroke 35mm
Lift of the presser foot Byhand Byhand: 5.5mm, By knee: 13mm
Needle (at the time of delivery) DBʷ1(#21)#16ʙ#23 or DPʷ5
Presser foot Fluorocarbon resin presser foot
Feed dog 3-row
Hook Automatic-lubricating full-rotary hook
Lubrication Automatic
Lubricating oil UKI Machine Oil No.7 (equivalent to ISO VG7)
Weight of the machine head  28kg
