Euro collarette 300

Automatic machine

Svegea's machines are economical yet robust.





Features

  • Soft start and stop, allows very high running speed, assuring the finest quality first to last meter.
  • Cuts virtually all tubular-knitted fabric. Band widths are easily and quickly adjustable.
  • Electronic soft start and stop assures highest quality at the beginning and end of each band roll.
  • Unique guide system to assure trouble-free cutting of most single jersey and terry products.
  • Cutting knives and pressure rollers are made of highest grade Swedish steel.
  • Auto stop feature when the band roll reaches the required preset size, up to a maximum of 280 mm (11 ½”)
  • Automatic major fabric flow detectors.
  • Safety guards to assure maximum operator protection.

Technical Features

TECHNICAL DATA Euro Collarette 300
Tubular Fabric width 35 cm* – 110 cm, (14″* – 43″) (*some elasticity required in the fabric)
Band width 16 mm – 170 mm*, (5/8″ – 6 3/4″*) (*small tubular diameter fabrics reduce the ability to cut the very wide bands)
Number of bands 4 (5 bands with additional knife unit)
Cutting capacity 4 x 0 – 60 m/min
Cutting system Scissor cutting & Crush cutting
Folded fabric Standard
Rolled fabric Extra, max 32″
Metre/yard counter Extra
Fabric hole detector This machine includes an efficient mechanical stop device
Festooner Extra
Anti-static device Extra
E-drive, electronic speed synchronization for fabric turntable Extra
True-drive: PLC-controlled speed-synchronization of fabric turn-table Extra
Dust Phantom, vacuum unit for removal of lint/dust Extra
Cut roll lifter Extra
